- Manufacturer: Case IH
- Model: Speed-Tiller 475
- Working Width, Minimum Ft/in [ M ]: 13.1 Ft [4.0 M]
- Working Width, Maximum Ft/in [ M ]: 41 Ft [12.5]
- Transport Width, Minimum Ft/in [ M ]: 8.2 Ft [2.9]
- Transport Width, Maximum Ft/in [ M ]: 15 Ft 9 In [4.8]
- Transport Height, Minimum Ft/in [ M ]: 11 Ft 10 In [3.6]
- Transport Height, Maximum Ft/in [ M ]: 13 Ft 1 In [4]
- Weight, Minimum Lbs [ Kg ]: 16535 [7500]
- Weight, Maximum Lbs [ Kg ]: 35650 [16170]
- Sizes Available, Number Of Widths: 6
- Blade Diameter Inches [ Mm ]: Std 24 In. [610 Mm]concavity Blades/ Opt. 22 In. [559 Mm] Shallow Concavity Blade
- Blade Spacing Inches [ Mm ]: 10 [250]
- Number Of Blades: 32, 36, 50, 66, 76 Or 100
- Primary Blade Type, Disk, Coulter Or Turbo: Disk
- Manufacturer's Description Of Blades: 22" (559) Shallow Concavity Std; 24" (61) Opt. Concavity
- Blade Edge Profile: Serrated Front And Rear
- Blade Depth Range - In (mm): 3 To 6 (76 To 152)
- Blade Mounting Description: Individual Arms; Rubber Torsion System; Two Gangs; Lateral Front Gang Adjustment
- Front Angle Of Gang Or Blades - °: 17 Degree Lateral; 8 Degree Incline
- Rear Angle Of Gang Or Blades - °: 17 Degree Lateral; 8 Degree Incline
- Attachment To Tractor, Mounted Or Trailing: Trailing
- Fore-aft Sequence Of Tillage Components: Disk-disk-conditioner
- Description, Basket, Reel Or Chopper: Crumbler Roller
- Rolling Diameter Inches [ Mm ]: 19 [480]
- Bars Or Blades On Circumference: Round Bars 1.44 (36.5) Dia.
- First Available Conditioner: Steel Spring Roller, 22 (560) Dia.
- Second Available Conditioner: Rubber Roller, 21 (533) Dia.
- Transport Tire, Largest Size: 560/45x22.5 Up To 600/50 R22.5 Std.; 425/65 X22.5 Opt.
- Wing Tire, Largest Size: 600/50 R22.5 Std.; 425/65x22.5 Opt.
- Engine Horsepower - Low Hp [ Kw ]: 150
- Engine Horsepower - High Hp [ Kw ]: 600 [447]
- Power Per Width Of Cut - Low Hp/ft [ Kw/m ]: 12 [29]
- Power Per Width Of Cut - High Hp/ft [ Kw/m ]: 15 [36]
- Advertised Tillage Speeds - Low Mph [ Kph ]: 8 [12.9]
- Advertised Tillage Speeds - High Mph [ Kph ]: 12 [19.3]
