Case IH RB456 HD Pro

Specifications

  • Manufacturer: Case IH
  • Model: RB456 HD Pro
  • Bale Width Inches [ Mm ]: 47.25 In. (120 Cm)
  • Bale Diameter - Minimum Inches [ Mm ]: 36 In. (90 Cm)
  • Bale Diameter - Maximum Inches [ Mm ]: 65 In (165 Cm)
  • Bale Weight - Maximum Lbs [ Kg ]: Up To 2,280 Lb. (1034 Kg)
  • Forming Mechanism, Belts, Rolls, Chain And Slats: 2 Rolls And Four Endless Belts
  • Belt Width Inches [ Mm ]: 10.4 In. (273 Mm)
  • Belt Description: Endless
  • Silage Version Available: Silage Capable
  • Cutter-chopper Available: Rotor Cutter And Rotor Feeder Available
  • Netwrap, Meshwrap Feature: 1 Active Roll, 2 Storage
  • Isobus Compatibility: Afs Pro 700 Monitor Option Or Tractor Monitor
  • Pickup Working Width Inches [ Mm ]: 90 In. (2.3 M)
  • Outer Tine-to-tine Width, Standard Inches [ Mm ]: 82 In. (2.07 M)
  • Number Of Tine Bars Or Tine Rows: 5
  • Overall Length, Gate Closed Inches [ Mm ]: 192 In. (4.87 M)
  • Overall Baler Width Inches [ Mm ]: 108 In. (2.74 M) On 500/55-20 Tires; 115 In. (2.91 M) On 620/40-22.5 Tires
  • Pto Speed Rpm: 1000
  • Drive Protection: Cut-out Clutch
  • Minimum Pto Power Required Hp [ Kw ]: 100 Rotor Feeder/120 Rotor Cutter
  • Number Of Hydraulic Remote Circuits: 2
