Case IH Magnum 280

Specifications

  • Manufacturer: Case IH
  • Model: Magnum 280
  • Classification Horsepower: 280
  • Drive Type: Wheeled Tractor
  • Drive Configuration: 4wd
  • Engine Power Hp [ Kw ]: 280 [206]
  • Maximum Power Hp [ Kw ]: 350 [257]
  • Pto Power Hp [ Kw ]: 235 [175]
  • 540 Available?: Optional
  • Engine Make: Case Ih Fpt
  • Engine Model: 8.7 Liter
  • Transmission Type: Full Powershift
  • Number Of Forward Speeds: 19
  • Number Of Reverse Speeds: 4
  • Implement Pump Flow Gallons (us) / Min [ Lt/min ]: 44 [166]
  • Number Of Remote Valves: 4 Std; 5 Or 6 Opt
  • 3-point Hitch Category: Category 3/3n
  • Standard Lift Capacity 24 Inches Behind Pin Lbs [ Kg ]: 14000 [6350]
  • Wheelbase/trackbase Inches [ Mm ]: 120 [3050]
  • Overall Width Inches [ Mm ]: 120 [3050]
