- Manufacturer: Case IH
- Model: Axial-Flow 7250
- Size Class: 7
- Horsepower, Rated Hp [ Kw ]: 402 [300]
- Horsepower, Maximum Hp [ Kw ]: 468 [349]
- Power Boost Hp [ Kw ]: 66 [49]
- Engine Make: Case Ih Fpt
- Engine Model: C11
- Number Of Cylinders: 6
- Piston Displacement Inches³ [ Ltr ]: 677 [11.1]
- Fuel Tank Capacity Gallons (us) [ Ltr ]: 297 [1124]
- Diesel Exhaust Fluid (def) Tank Capacity Gallons (us) [ Ltr ]: 43 [166]
- Feeder Width Inches [ Mm ]: 54 [1372]
- Feeder Speed Variable: Standard
- Feeder Reverser Control: Electro-hydraulic
- Feeder Tilt Adjustment: Fore-aft Std; Lateral Std.
- Stone / Rock Protection: Spiral Beater/sump, Optional
- Threshing System Type, Rotary Or Conventional Cylinder: Longitudinal Rotor
- Number Of Rotors Or Cylinders: 1 Rotor
- Rotor Or Cylinder Description: Staggered Rasp Bars
- Rotor Or Cylinder Diameter Inches [ Mm ]: 30 [762]
- Rotor Or Cylinder Length Inches [ Mm ]: 102.8 [2612]
- Rotor Or Cylinder Speed Range - High Rpm: 1180
- Rotor Or Cylinder Speed Range - Low Rpm: 220
- Threshing Area Wrap °: 180
- Concave Adjustment: Electronic, W/position Sensor
- Total Sieve Area In² [ M² ]: 10075 [6.5]
- Leveling System Available: Self-leveling To 12.1%
- Cleaning Fan Description: 15.4" (391) Dia. Cross Flow
- Cleaning Fan Speed Range - High Rpm: 1150
- Cleaning Fan Speed Range - Low Rpm: 300
- Grain Tank Capacity, Standard Bu (us) [ L ]: 315 [11100]
- Optional Grain Tank Capacity Bu (us) [ L ]: 410 [14448]
- Unloading Rate Bu (us)/s [ L/s ]: 4 [141]
- Unloading Auger Length, Standard Ft/in [ M ]: 28 Ft 9 In [8.8]
- Reference Drive Tire Size: If800/70r38
- Steering Tire Size: Vf600/70 R28 Cfo, R1w
- Rubber Tracks Available: 30" Or 36" Factory Fit
- Weight Lbs [ Kg ]: 42245 [19162]
- Wheelbase, 2wd Inches [ Mm ]: 148 [3759.21]
- Transport Height Ft/in [ M ]: 13 Ft 1 In [4]
- Optional Auger Length Ft/in [ M ]: 50 Ft [15.2]
