Spécifications
- Manufacturier : Case IH
- Modèle : L565
- Mechanical (msl), Hydraulic (hsl), Or Non-self-leveling (nsl) : Mechanical
- Matching Tractor Model Or Series, First : Farmall 65c, 75c
- Tractor Tires Listed In Loader Specification : 280/85 R24 Front; 420/85 R30 Rear
- Lift Capacity To Maximum Height, At Bucket Pivot Pin Lbs [ Kg ] : 2340 [1060]
- Lift Capacity To Max. Height, 31.5" (800 Mm) Forward Of Bucket Pivot Pin Lbs [ Kg ] : 2600 [1180]
- Lift Capacity To 59" (1.5 M) Height, At Bucket Pivot Pin Lbs [ Kg ] : 2890 [1310]
- Lift Capacity To 59" (1.5 M) Height, 31.5" (800 Mm) Forward Of Pivot Pin Lbs [ Kg ] : 2990 [1355]
- Maximum Lift Height To Bucket Pivot Pin Inches [ Mm ] : 122 [3090]
- Maximum Lift Height Under Level Bucket Inches [ Mm ] : 113 [2860]
- Clearance With Bucket Dumped 45 Degrees, Lowest Point Of Cutting Edge Inches [ Mm ] : 89 [2270]
- Boom Breakout Force, At Pivot Pin, Bucket At Ground Lbf [ Kn ] : 3850 [17.1]
- Boom Breakout Force, 31.5" (800 Mm) Forward Of Bucket Pivot Pin At Ground Lbf [ Kn ] : 3380 [15]
- Bucket Rollback Force At Max. Height, 31.5" (800 Mm) Forward Of Pivot Pin Lbf [ Kn ] : 2475 [11]
- Bucket Rollback Force At 59" (1.5 M) Height, 31.5" (800 Mm) Forward Of Pivot Pin Lbf [ Kn ] : 3350 [14.9]
- Bucket Rollback Force At Ground, 31.5" (800 Mm) Forward Of Pivot Pin Lbf [ Kn ] : 3200 [14.2]
- Reach At Maximum Lift Height, Bucket Cutting Edge To Tractor Front, Bucket Dump At 45 Degrees Inches [ Mm ] : 37 [950]
- Reach With Bucket On Ground, Level, From Centerline Of Front Wheels To Bucket Cutting Edge Inches [ Mm ] : 85 [2160]
- Maximum Dump Angle, Loader Fully Raised ° : 50
- Maximum Rollback Angle, Bucket At Ground ° : 42
- Digging Depth, From Ground Line To Bottom Of Bucket With Cutting Edge Horizontal Inches [ Mm ] : 6.7 [170]
- First Coupler Type Available : Skid-steer Style
- Second Coupler Type Available : Euro Style Dealer Install
- Third Function Valve Available : Dealer Install
- Cushioned Hydraulic Ride Control : Dealer Install
- Loader Quick-attach-detach From Tractor : Standard
