- Manufacturier : Case IH
- Modèle : Farmall Utility 90C
- Classification Horsepower : 90
- Drive Type : Wheeled Tractor
- Engine Power Hp [ Kw ] : 86 [64]
- Maximum Power Hp [ Kw ] : 86 [64]
- Pto Power Hp [ Kw ] : 73 [54]
- 540 Available? : Yes
- 540e Available? : Yes
- Engine Make : Case Ih Fpt
- Engine Model : 3.4 L
- Transmission Type : 4 Synchro Gears, 3 Non-synchro Ranges
- Number Of Forward Speeds : 12
- Number Of Reverse Speeds : 12
- Maximum Speed Forward - Mph (kph) : 18.6 Or 25 (30 Or 40)
- Implement Pump Flow Gallons (us) / Min [ Lt/min ] : 0 [64]
- Number Of Remote Valves : 2 Std; 3 Opt
- 3-point Hitch Category : Category 2
- Standard Lift Capacity 24 Inches Behind Pin Lbs [ Kg ] : 4339 [1968]
- Wheelbase/trackbase Inches [ Mm ] : 90 [2285]
- Length Inches [ Mm ] : 160 [4064]
- Height To Top Of Cab Inches [ Mm ] : 102 [2594]
- Height Of Top Of Rops Inches [ Mm ] : 106 [2700]
- Overall Width Inches [ Mm ] : 76 [1923]
- Weight, Total Allowable Lbs [ Kg ] : 9392 [4260]
