- Manufacturier : Case IH
- Modèle : Farmall Compact 35A
- Classification Horsepower : 35
- Drive Type : Wheeled Tractor
- Engine Power Hp [ Kw ] : 35 [26]
- Maximum Power Hp [ Kw ] : 35 [26]
- Pto Power Hp [ Kw ] : 29.7 [22.1]
- 540 Available? : Yes
- Engine Make : Ls Mtron
- Engine Model : L3c19-t
- Transmission Type : 4 Gears, 3 Ranges, Non-synchro
- Number Of Forward Speeds : 12
- Number Of Reverse Speeds : 12
- Maximum Speed Forward - Mph (kph) : 14.2 (22.9) Mech; 13.8 (22.2) Hst
- Implement Pump Flow Gallons (us) / Min [ Lt/min ] : 8.2 [31]
- Number Of Remote Valves : 1 Opt
- 3-point Hitch Category : Category 1
- Standard Lift Capacity 24 Inches Behind Pin Lbs [ Kg ] : 1433 [650]
- Standard Lift Capacity At Lift Pin Lbs [ Kg ] : 1808 [820]
- Wheelbase/trackbase Inches [ Mm ] : 67.5 [1715]
- Length Inches [ Mm ] : 145 [3688]
- Height Of Top Of Rops Inches [ Mm ] : 88.2 [2241]
- Overall Width Inches [ Mm ] : 66.5 [1690]
